Liquid-cooled FC System
Hydrogen Power Module for Electric Mobility
Rated Voltage
48VDC
Rated Power
3kW~10kW
Max Power
4kW~20kW
Dimension(mm)
706.5x927x370.5
Weight(kg)
100
Ingress Protection
IP54
Operating Temperature(°C)
0~45
3kW Hydrogen Power Generator
Rated Voltage
48VDC
Rated Power
3kW
Max Power
4kW
Dimension(mm)
902x652x750
Weight(kg)
80
Ingress Protection
IP54
Operating Temperature(°C)
0~45
5kW Hydrogen Power Generator
Rated Voltage
48VDC
Rated Power
5kW
Max Power
6.5kW
Dimension(mm)
650x650x1500
Weight(kg)
150
Ingress Protection
IP54
Operating Temperature(°C)
0~45
80kW Hydrogen Power Generator
Rated Voltage
380VAC
Rated Power
80kW
Max Power
88kW
Dimension(mm)
3300x1100x2248
Weight(kg)
3400
Ingress Protection
IP43
Operating Temperature(°C)
-10~45
MW Hydrogen Power Container
Rated Voltage
Customized
Rated Power
Customized
Max Power
Customized
Dimension(mm)
Customized
Weight(kg)
Customized
Ingress Protection
Customized
Operating Temperature(°C)
Customized
